Raft

Raft is a consensus algorithm for keeping a replicated state machine consistent across a cluster of servers. Each server applies the same commands in the same order, so the cluster behaves like one reliable machine even when a minority of its servers fail.¹

Raft was designed as a more understandable alternative to Paxos. It divides consensus into separate problems, most importantly leader election and log replication, while providing equivalent fault tolerance and performance.¹

Server states

Each server is in one of three states:

• Follower: accepts log entries and heartbeats from the leader.
• Candidate: asks the other servers for votes when it believes the leader has failed.
• Leader: accepts client commands and replicates them to the followers.

Time is divided into numbered terms. A term begins with an election and normally continues under one leader. A server returns to the follower state when it learns of a newer term.

Leader election

The leader sends regular heartbeats. If a follower does not receive one before its randomized election timeout, it becomes a candidate, increments the term, votes for itself, and requests votes from the other servers. A candidate that receives votes from a majority becomes the leader.²

Randomized timeouts make it less likely that several followers start an election at once. If no candidate wins, the servers start another term and try again.

Log replication

The leader handles every client command in the same sequence:

1. Append the command to its own log.
2. Send the entry to the followers.
3. Commit the entry once a majority has stored it.
4. Apply the committed command to the state machine and tell the followers to do the same.

A five-server cluster can therefore continue with two failed servers. It stops making progress when it loses its majority, but it does not commit a conflicting result.¹

The leader also repairs inconsistent follower logs. It finds the last entry where the two logs agree, removes the follower's conflicting suffix, and sends the missing entries again. Raft's voting rules prevent a server with an outdated log from becoming leader and losing already committed commands.²

Raft assumes servers may crash or become unreachable; it does not protect against servers that lie or act maliciously. In other words, it is crash fault tolerant, not Byzantine fault tolerant.²
